Air Handling Unit

Custom-designed AHUs for precise air circulation, filtration and temperature uniformity in cold storage and clean rooms.

Air Handling Unit (AHU)

SHAKTI INDUSTRIES | Concept to Commissioning

Custom Air Handling Units for Controlled Environments

SHAKTI INDUSTRIES manufactures Air Handling Units (AHUs) engineered for mushroom growing rooms, ripening chambers, cold stores, and clean-room environments. Our AHUs deliver precise control of temperature, humidity, CO2, and fresh air exchange.

Each unit is custom-sized for the room volume and designed for uniform air distribution throughout the growing or storage space, eliminating hot spots and ensuring consistent produce quality.

Applications: Mushroom growing rooms, casing rooms, composting tunnels, ripening chambers, cold stores, pharmaceutical clean rooms, and food processing environments.

AHU Components & Design

Our air handling units are built with premium-grade components for reliability and energy efficiency in continuous-duty applications.

Low-noise centrifugal / axial fans
DX cooling coil / chilled water coil
Electric / steam / hot water heating coil
Ultrasonic humidifier integration
HEPA / G4 / F7 filtration sections
Fresh air damper & recirculation damper
CO2 sensor port & gas mixing section
SS / GI double-skin insulated casing

Why Choose SHAKTI AHUs?

Custom-designed for each room's volume
EC fan motors for energy saving (up to 50%)
Uniform airflow with no dead zones
Integrated humidifier & CO2 control
PLC control with remote SCADA access
Easy maintenance access panels

Our AHUs meet the exacting air management requirements of mushroom cultivation, where consistent temperature, humidity, CO2, and fresh air are critical for yield and quality.

Technical Specifications

Airflow Range500 m³/hr – 50,000 m³/hr
Cooling Capacity1 TR – 50 TR
Temperature Control+2°C to +35°C
Humidity Control60% – 98% RH
CO2 Control500 – 5000 ppm (optional)
Fan TypeCentrifugal / Axial (EC motor)
Coil MaterialCopper tube / Aluminium fins
CasingGI / SS double-skin insulated
Filter GradeG4 / F7 / HEPA (application-based)
Control SystemPLC / BMS integration ready

Control & Monitoring Parameters

Measuring Functions
  • Room Air Temperature
  • Relative Humidity
  • CO2 Concentration
  • Supply Air Temperature
  • Airflow Velocity (m/s)
Controlling Functions
  • Cooling / Heating Setpoint
  • Humidity Setting
  • Fan Speed (VFD)
  • Fresh Air Damper Position
  • CO2 Alarm & Ventilation
